Rotary Table Adapter

  • Writer: Joseph Boettcher
    Joseph Boettcher
  • Aug 13, 2025
  • 1 min read

I made this rotary table adapter on my mill to be able to hold parts and index them then drill or mill. It uses a 1/2-20 mt3 arbor to locate the center of the rotary table, it has a morse taper hole in the center. This makes it easy to indicate off the circular hole on the center of the rotary table then install the chuck and adapter and perform your work.
